The VWR® thermal cycler family combines high quality engineering with a comprehensive range of block formats. The UNO cycler is designed around a powerful, yet easy to use, software interface, and uses the same platform for both 96-well and 384-well formats. The Doppio, with two independent high speed 48-well blocks in one system, offers the optimum solution for maximum flexibility within a minimum footprint. Because of the special design of the heated lid, the height adjusts automatically to the different tube sizes.
Outstanding performance: Thermal plate with impressive thermal characteristics; powerful Peltier elements with Long Life Technology; heat sink with cooling fans with magnetic bearing enabling rapid temperature change control of up to 5 °C/s
Reliable, reproducible results: 8, 2×8 or 16 Peltier elements control the temperature row by row, enabling an outstanding block homogeneity of ±0,2 °C and the choice of absolute linear gradients and independent lane control
Simple to use: Sharp, clear TFT display and intuitive touch screen commands
Data control: Up to 4×USB, 1×ethernet (MS Windows®, Linux), remote control and monitoring of instruments via PC software, MP3 signal tones, user calls via email and primary/replica control
All systems include simple to use PC software for remote control and monitoring of instruments, plus creating PCR protocols on the PC.
FlexGradient technology (option for UNO and Doppio only): With the temperature of the 8 rows each individually controlled, select between a perfectly linear temperature gradient (ideal for PCR optimisation), or independent lane control (ideal for the use of different primer pairs in the same run). System tools at the touch of a button: Graphical or tabular programming, 'Global Program Ramp', 'Gradient Control', 'Tube Control', Emulation mode, online help, 'Quickstart' function and 'Power Fail Denaturation' for auto-restart after power failure. High specification remote control: State of the art technology, with VWR 'PCR Cycler Master Software'; receive notifications via email, or use the system MP3 player. Emulation mode: For easy transfer of PCR protocols.
Engineered and manufactured in Germany according to ISO 9001, calibrated and maintained according to NIST standards, and backed with more than 20 years of cycler expertise and experience.
Thermal cycler, UNO96, with 96-well universal block and standard lid for 96×0,2 ml tubes, 96-well PCR plates or 48×0,5 ml tubes with flat caps
1 item
732-2914
UNO96 HPL
Thermal cycler, UNO96 HPL, with 96-well universal block and high pressure lid (HPL, 100–250 N) for 96×0,2 ml tubes, 96-well PCR plates or 48×0,5 ml tubes with flat caps
1 item
732-2915
UNO96 HPL Gradient
Gradient thermal cycler, UNO96 HPL Gradient, with 96-well universal gradient block and high pressure lid (HPL, 100–250 N) for 96×0,2 ml tubes, 96-well PCR plates or 48×0,5 ml tubes with flat caps
1 item
732-2549
UNO96 Gradient
Gradient thermal cycler, UNO96 Gradient, with 96-well universal gradient block and standard lid for 96×0,2 ml tubes, 96-well PCR plates or 48×0,5 ml tubes with flat caps
1 item
732-2550
UNO384
Thermal cycler, UNO384, with 384-well block and high pressure lid for 384-well PCR plates
1 item
732-2551
Doppio
Thermal cycler, Doppio, with 2×48-well universal blocks and standard lids for 48×0,2 ml tubes or 24×0,5 ml tubes with flat caps per block
1 item
732-2552
Doppio Gradient
Gradient thermal cycler, Doppio Gradient, with 2×48-well universal gradient blocks and standard lids for 48×0,2 ml tubes or 24×0,5 ml tubes with flat caps per block
Sample capacity
96×0,2 ml tubes, 96-well PCR plates or 48×0,5 ml tubes with flat caps; Sample volume range per well 10 – 100 µl (20 - 50 µl recommended) / 384-well PCR plates; Sample volume range per well 5 – 20 µl (5 - 10 µl recommended) / 48×0,2 ml tubes or 24×0,5
