The SE640 is an extra wide vertical protein electrophoresis unit that accomodates up to 112 samples at one time.
Features:
- Maximum glass plate size 18 x 8 cm
- Permits rapid screening of up to 112 samples at one time
- Design permits gels to be surrounded uniformly by buffer so heat dissipation is efficient.
- Bands are sharp and lanes are straight
- Accommodates denaturing or native polyacrylamide gels
- Run up to four second dimension gels using IEF strips or tube gels
Complete Unit (SE640-15-1.5) Includes:
- Lower Buffer Chamber
- Upper Buffer Chamber
- Safety Lid with High Voltage Leads
- Glass Plates 18 x 8 cm, 6 pcs
- 8 cm Clamp Assemblies, 4 pcs
- Cams, 6 pcs
- Dual Casting Stand with Leveling Base
- Laminated Gaskets for Casting Stand, 2 pcs
- Slotted Gaskets for Upper Buffer Chamber, 2 pcs
- Buffer Dam
- Spacer-Mate Alignment Template
- Wonder Wedge Plate Separation Tool
- Gel Seal
- Bubble Level
- Combs, 15-well, 1.5 mm thick, 2 pcs
- 1.5 mm Thick Spacers, 2 cm wide, 4 pcs
Basic Unit (SE640) Includes:
The same as above without the combs and spacers. Order two SE511 combs and two sets of 8 cm long spacers separately.
Specifications:
|
Glass Plate Size(W x H)
|
18 x 8 cm |
| Spacers |
0.75 mm, 1.0 mm, 1.5 mm |
| Maximum Power Settings |
1000 V, 500 mA, and 50 W |
| Maximum Temperature |
45°C |
| Indoor Use |
4 to 40°C |
| Humidity |
Up to 80% |
|
Unit Dimensions(W x H x D)
|
32 x 29 x 14 cm |
