SIRscan Orion - The only automated system capable of performing the incubation and reading of agar-based antibiograms (Kirby Bauer Method) automatically.
Reading Parameters
- Reading of all germs in all types of media*.
- High-resolution colour camera.
- Detection of double zones and weak growths.
- Automatic backup of all images.
- Displayed image remains unaltered.
- Performs 100% of the laboratory's antibiograms* (Kirby Bauer Method).
- Continuous reading.
- Rate = 60 boxes/h.
Expertise and Validation
- Automatic or deferred reading of results.
- Automatic sending of results validated by the expert reader.
- Possible validation from a remote workstation: visual control.
- Workflow management: dashboard.
Loading
- Removable racks.
- 4 racks of 11 plates each.
- Continuous loading option.
- Integrated control screen.
Incubation
- Automatic incubation.
- Electronically regulated temperature.
- Result times:
- MHR SIR: 6 to 8 hours.
- MH/ISO: 14 to 18 hours.
- Temperature management and monitoring.
- 4 independent compartments.
- Separate and ventilated boxes.
Safe and Secure
- Controlled access.
- Archives with remote access.
- Detection of symbols and automatic management of i2a disc batch numbers.
- Universal expert system for the validation of ID/ATG results.
- Advanced traceability.
- Images archiving.
* Refer to the current recommendations.
Software
SIRxpert - microbiology middleware: universal open system for the interpretative reading of antibiograms.
- A comprehensive and user-friendly interface.
- Management of raw AST results.
- Automated expertise and interpretation of AST.
- Validation control (result consistency).
- Automatic export and import to the LIS or other systems (SIRxpert interface option).
- Fully configurable and customizable.
- Optional epidemiology module.
- Monitoring of international standards (CLSI, EUCAST, CASFM).
Specifications
| Plates read | Round 90 mm, Round 140 mm (150 mm with lid), Square 120 mm |
| System components | SIRscan Orion reader/incubator with a 4-rack incubator; 24" touchscreen; PC; Webcam for assistance; SIRxpert Antibiogram software; SIRxpert Antibiotic Susceptibility Testing Flow software; SIRxpert Bidirectional |
| Accessories | Barcode printer; Barcode scanner |
| Options | Support table; Articulated arm for screen, mouse, keyboard and barcode reader; SIRxpert Abbreviations (when using i2a discs); SIRxpert batch traceability (when using i2a discs) |
| Incubator | 4 racks of 11 plates each, 4 independent temperature-regulated compartments, continuous loading |
| Throughput | 60 plates per hour |
| Time to result | MHR-SIR: 6 to 8 hours; MH / ISO: 14 to 18 hours |
| Dimensions (W x H x D) | 1063 W x 1124 H x 763 D mm |
| Net weight | 196.4 kg (empty) |
| Mains voltage | 100-240 VAC, 50-60 Hz |
| Power consumption | 350 W max |
| Heat dissipation | 1364 Btu/hr |
| Noise level | 55 dB max |
| Installation category / pollution degree | II / 2 |
| Manufacturer | i2a (Montpellier, France) |
| Regulatory status | CE-marked in vitro diagnostic medical device (IVDR) |
Ordering
| Code | Price-list description | Package |
|---|---|---|
| P30D-S-ORION | SIRscan ORION Package | Standard package |
| P30D-N-ORION | SIRscan ORION Nude Package | Nude package |
Documents
Specifications
- Applications Automated antibiotic susceptibility testing (incubation, reading, expert interpretation)
- Assay time MHR-SIR 6-8 h; MH/ISO 14-18 h
- Capacity 4 racks x 11 plates (90 mm, 140 mm round; 120 mm square)
- Compatible with SIRscan Discs, MHR-SIR media, i2a disc dispensers
- Country of origin France
- Dimensions 1063 x 1124 x 763 mm (W x H x D)
- Electrical 100-240 VAC, 50-60 Hz, 350 W max
- Method Agar disc diffusion AST (Kirby-Bauer)
- Model SIRscan Orion
- Noise 55 dB max
- Regulations CE IVD (IVDR)
- Software SIRxpert Antibiogram, AST Flow, Bidirectional
- Sub category Antibiogram Incubator-Readers
- Technology Automated incubation and HD colour-camera reading of disc-diffusion antibiograms
- Throughput 60 plates/h
- Weight 196.4 kg (empty)
