10 µL, Gastight Syringe, Cemented Needle, Gel Loading
Vendor: Hamilton Company
SKU: 84504
In stock
Hamilton's 1700 series, Gastight Instrument # 1725 Diluter PTFE Luer Lock (D) Syringe with X-Style plunger has a PTFE Luer Lock male fitting with an M6 female side port. The X-style plunger is intended for use with syringe pumps, diluters, and dispensers. A special plunger button protects the delicate plunger wire by stopping the pump at the zero line before damaging the tip. The Hamilton 1700 series syringes are Gastight versions of the 700 series, ideal for dispensing liquids and gases. Their polymer plunger tip ensures a leak-free seal. These syringes offer up to 1% accuracy, superior durability, and are made from high-quality, chemically resistant materials.
Specifications
| Volume | 10 µL |
|---|---|
| Syringe Type | Gastight |
| Syringe Series | 1700 |
| Termination | Cemented Needle (N) |
| Needle | Cemented Needle |
| Gauge | 0.4 mm |
| Point Style | 3: Blunt |
| Needle Length | 1.00 inch (25.4 mm) |
| Plunger Style | Standard Plunger |
| Fluid Path | SST, Borosilicate glass, PTFE |
| Autoclavable | No |
| Gas Sterilizable | Yes |
| Pressure | 1000 psig (68.9 bar) |
| Maximum Operating Temperature | 50°C / 122°F |
| Minimum Operating Temperature | 10°C / 50°F |
| Barrel Inner Diameter | 0.018 inches (0.460 mm) |
| Barrel Outer Diameter | 0.260 inches (6.60 mm) |
| Needle Inner Diameter | 0.004 inches (0.10 mm) |
| Needle Outer Diameter | 0.016 inches (0.41 mm) |
| Std Needle Dead Volume | 0.88 µL |
| Sales Quantity | 1 syringe per pack |
| Syringe Model Number | 1701 |
Documents
Specifications
- Autoclavable No
- Barrel inner diameter 0.018 inches (0.460 mm)
- Barrel outer diameter 0.260 inches (6.60 mm)
- Fluid path SST, Borosilicate glass, PTFE
- Gas sterilizable Yes
- Gauge 0.4 mm
- Maximum operating temperature 50°C / 122°F
- Minimum operating temperature 10°C / 50°F
- Needle Cemented Needle
- Needle inner diameter 0.004 inches (0.10 mm)
- Needle length 1.00 inch (25.4 mm)
- Needle outer diameter 0.016 inches (0.41 mm)
- Plunger style Standard Plunger
- Point style 3: Blunt
- Pressure 1000 psig (68.9 bar)
- Sales quantity 1 syringe per pack
- Std needle dead volume 0.88 µL
- Sub category Gastight Syringes
- Syringe model number 1701
- Syringe series 1700
- Syringe type Gastight
- Termination Cemented Needle (N)
- Volume 10 µL
links and documants
- Catalog url Click here
- Guide url Click here
- Source url Click here
- Specification url Click here
